Specifications - Tad Micro Evolution One Mode D'emploi

SPECIFICATIONS

Model Name
TAD Micro Evolution One
Model No.
TAD-ME1
Design
Bass reflex, bookshelf-type speaker
Drive units
Bass driver ...................................................... 16 cm (6 1/2 in.) cone
Midrange/Tweeter
............ concentric 9 cm (3 1/2 in.) cone/ 2.5 cm (1 in.) semi-dome
Performance Data
Frequency Range .......................................................36 Hz to 60 kHz
Crossover Frequencies ...................................... 420 Hz, and 2.5 kHz
Maximum input power ............................................................. 150 W
Sensitivity ..............85 dB @ 2.83 V and 1 m (anechoic conditions)
Impedance .............................................................................. 4 ohms
Physical Data
Weight ........................................................................... 20 kg (44 lbs)
Dimensions
Width ................................................................ 251 mm (9 7/8 in.)
Height ........................................................... 411 mm (16 3/16 in.)
Depth .......................................................... 402 mm (15 13/16 in.)
Supplied accessories
Accessory folder
 This Owner's Manual x 1
 Cleaning cloth x 1
 Warranty card (This warranty is valid only in Japan.)
Accessory parts
 Non-slip pad x 4
 Shorting links x 2
10
Note
Included parts may vary slightly by region.
The specifications and construction details in this and related
TAD publications are subject to change without notice. The TAD
logo is a registered trademark of Technical Audio Devices, Inc.
411mm
251mm
Figure 6. Overall dimensions of the TAD Micro Evolution One
speaker system
371mm
402mm
156mm
160mm
Screw hole (M6) for
linking stand to speaker
