Operation instructions
• Display
When electrify the refrigerator,, the display screen will total display for 3 seconds. Meanwhile the
starting up bell rings and then the screen enters the normal display of the operation.
The first time for using the refrigerator, the default set temperature of refrigerating chamber and
freezing chamber is 4° C/-18 °C respectively.
When the error occurs, the display shows the error code (see next page); during normal running, the
display shows the set temperature of the refrigerating chamber or freezing chamber.
Under normal circumstances, if there is no operation on display panel or door opening action within
30s, then the display is lock, and the sate
• Lock /unlock
In the unlocked state, long press the lock button
logo goes outand buzzer sounds, it means the display panel is locked, at this time, button operation
cannot be implemented;
In the locked state, long press the lock button
the logo lights up and buzzer sounds, it means the display panel is unlocked, at this time, button
operation can be implemented;
• Temperature setting of refrigerating chamber
Press temperature zone selection button
refrigerating chamber, and then press
chamber. The temperature setting range for refrigerating chamber is 2°C ~ 8°C.
• Temperature setting of freezing chamber
Press temperature zone selection button
freezing chamber, and then press
temperature setting range for refrigerating chamber is -24°C~ -16°C.
• Temperature setting of variable temperature chamber
Press Variable temperature button
the adjusting range is Fruit/vegetable, drink and chilled.
• Mode setting
Set the Super cooling mode: after the temperature of the refrigeration room is adjusted to 2°C, press
the temperature down button "
temperature of the refrigerating chamber is automatically set to 2°C.
Exit the Super cooling mode: press the temperature up button " " to exit the super cooling mode or
automatically exit the super cooling mode after 6h.
After exiting the super cooling mode, the temperature of the refrigerator will automatically return to the
temperature set before the super cooling mode
Set the super freezing mode: after the temperature of the freezing chamber is adjusted to -24°C, press
the temperature down button "
temperature of the freezing chamber is automatically set to -24°C
Exit the super freezing mode: press the temperature up button "
automatically exit the super freezing mode after 32h. After exiting the super freezing mode, the freezing
chamber temperature will automatically return to the temperature set before the super freezing mode.
According to IEC62552:2007,the test condition as follow:
start the super freezer mode in advance, and wait when the fridge enters automatic defrosting after 18
hours, and then apply the freezer load. The maximum defrosting time is 72 hours and the minimum is 12
hours at 32°C.
Recommended setting : Refrigerated chamber 4°C freezing chamber -18°C.
NOTE
The quick-freezing function is designed to maintain the nutritional value of the food in the freezer. It can
freeze the food in the shortest time. If a large amount of food is frozen at one time, it is recommended
that the user turn on the quick-freezing function and put the food in. At this time, the freezing speed of the
freezer compartment is increased, which can quickly freeze the food, effectively lock the nutrition od the
food, and facilitate storage.
goes out.
to choose the setting temperature zone of
or to adjust the setting temperature of refrigerating
to choose the setting temperature zone of
or to adjust the setting temperature of freezing chamber. The
to adjust the setting temperature of the chamber,
" to enter the super cooling mode. In the super cooling mode, the
" to enter the super freezing mode. In the super freezing mode, the
8
for 3 seconds, enter the lock state, the
for 3 seconds, enter the unlocked state,
" to exit the super freezing mode or
ENG
