Configure the XBee® RR USB Adapter
Connect the XBee® RR USB Adapter
The XBee® RR USB Adapter requires a device driver, FT232R. To download this device driver, go
to
ftdichip.com/drivers/vcp.htm
The USB connection is converted to UART communications and are connected to DIN, DOUT,
RTS, CTS and DTR of the XBee® RR USB Adapter device.
Programming options
There are many options to consider when making wireless programmatic access to an XBee
network of devices or device adapters. In broad terms, you can write a program which runs on a
computer to interact with a network or you can use a gateway device.
When using a computer, consider using Command mode for the XBee device attached to the
computer. Although using this mode is straight forward it does not offer you as fine of control as
when using the API mode option.
You can also use Digi Remote Manager to program the XBee® RR USB Adapter; see the
Remote Manager Programming Guide
Configure the XBee® RR USB Adapter
For information on configuring the XBee® RR USB Adapter, see the user guide for the protocol you
are running:
XBee RR Zigbee RF Module User Guide
n
Hardware reset
There is no external access to the hardware reset pin on the XBee® RR USB Adapter. If a
hardware reset is required, hold the UART break line for an extended time to hardware reset the
XBee® RR USB Adapter.
Hardware reset will occur between 4 and 20 seconds.
Digi XBee® RR USB Adapter User Guide
and select the download appropriate for your operating system.
.
Connect the XBee® RR USB Adapter
