Installing and removing the woofer grille
A magnetically-attached woofer grille is included in the package.
Magnets are embedded at six locations as shown in the figure
below.
How to install: Install the woofer grille so that the magnets are
positioned as shown in the figure below.
How to remove: Pull the grille toward you to remove it as shown in
the figure below.
Please remove the woofer grille when using or cleaning this
speaker system. Also, if you apply horizontal force while it is
attached, the grille may fall.
Grille side
Installation of Spikes
Caution
Please be sure to screw all the way in when installing spikes.
The installation surface can be securely established by using
spikes.
Spikes are screwed into the screw holes, which are positioned at
three locations on the bottom surface of the cabinet.
Installation can be performed with no rattling of the installation
surface and requiring no fine adjustment of spike heights, by
providing support at three locations.
Once the installation location is decided by referencing the
section about Choosing Where To Place The Speakers on page 7,
install the spikes and the tumble prevention spikes.
6
Enclosure side
1. Screw in spikes at three locations on the bottom surface of the
base (two in front and one in
2. Place spike receivers at locations where spikes will be
positioned, then place the speaker on top of the spike receivers.
3. Adjust the length of the fall prevention spikes to ensure that
there will be no rattling, then tighten them with nuts.
CAUTION
・ Place the speaker on top of something that would
not scratch it, such as a soft cloth, to perform
installation of the spikes.
・ Place spike receivers with the center indentation
facing up, as shown in the diagram below.
・ Using spikes without using spike receivers can
potentially leave scratches on the surface where the
speaker is installed, such as the surface of the floor.
back).
