5. Use the channel fader to make the desired settings.
6. Press the / EDIT / REC / button to save the scene. To confirm the memory process, all the LEDs on the
controller flash three times.
7. Press and hold the / INSTER / TAP / button until the LED next to the button goes out.
8. Press and hold the / EDIT / REC / button to exit the programming mode.

2.3.5 Delete scene from a rchaser (running light sequence):

1. Press the / EDIT / REC / button for two seconds. Control LED is on.
2. Use the / CHASE 1-16 / buttons to select the sequence to be edited. The display shows: e.g.
S010
3. Use the / ◄ / and / ► / buttons to select the sequence step (scene) to be deleted.
4. Press / DEL / CLR / to delete. To confirm the memory process, all the LEDs on the controller flash three times.
5. Press and hold the / EDIT / REC / button to exit the programming mode.

2.3.6 Playing a chaser (running light sequence):

A chaser can run manually, time-controlled or music-controlled. The MANUAL, AUTO and MUSIC LEDs show the
current setting.
Call up the running sequence manually.
Make sure that the manual mode is activated. The LED / MANUAL / must light up.
1. Use the / CHASE 1 to 16 / buttons to select the desired sequence.
2. Press the / ◄ / and / ► / buttons to display individual / STEPS / (scenes).
Runs the sequence automatically.
In automatic mode, the scenes stored in a memory bank are played back in a loop in a time-controlled manner.
1. Press the / RUN MODE / button to switch to / AUTO / operation.
2. Use / CHASE 1 to 16 / to select the desired sequence.
3. Now you can set the speed with the / WAIT TIME / fader and the fade time with the / FADE TIME / fader. The
values are displayed in seconds when the display is set.
You can also set the sequence by pressing the / INSTER / TAP / button. The distance between two key steps
corresponds to the interval sequence.

2.4 Stroboscope function:

When you press the / STROBE / button, all running programs and scenes are interrupted and the strobe is
activated.
You can individually assign channels for each device that are to flash when the / STROBE / button is pressed.
Pressing / STROBE / button will flash all assigned channels of all devices in the current configuration. All other
channels remain off (value 0).
Useful applications of the / STROBE / function are for example:
Device type
RGB LED PAR/Spot
RGBW LED PAR/Spot
Moving Light
Stroboskope
1. Press and hold the / EDIT / REC / button for two seconds. The control LED next to the button lights up.
2. Press the / STROBE / button. The control LED next to the button lights up.3. Wählen Sie mit den Device
Assignable channels
Dimmer-Channel, Red, Green and Blue
Dimmer-Channel, White
Dimmer- Channel, Shutter-Channel
Dimmer- Channel, Strobe- Channel
20
