in.xtend TechBook

Keypad configuration selection

As each keypad has its own output configuration
(number of outputs which can be controlled, excluding
light), the inxtend-pk has a jumper to select the right
configuration This is based on the individual options
of the keypad (1 OP, 2 OP, etc) The correct output
configuration can be found in the keypad model name,
such as ink450-3OP-  The jumper connector is
located in the front (see image)
Select the correct configuration on your in.xtend-pk according to the following table:
K-8, K-45, K-52, K-56,
Outputs K-5
1 OP
2 OP
3 OP Pos 1
4 OP Pos 2
5 OP

Maximum distance

The maximum distance depends on the keypad See below for the maximum distance possible for each keypad,
when used with a CAT5E cable (24AWG):
Keypad
K-5
K-8, K-45, K-52, K-56, K-72, K-73, K-85
ink100
ink3xx
ink4xx
ink6xx
in.k100
K-72, K-73, K-85
Pos 4
Pos 5
Pos 1 Pos 1
Pos 2
Pos 3 Pos 2
Jumper connector
in.k3XX in.k4XX
Pos 2 Pos 8
Pos 1 Pos 9
Pos 10
Maximum distance (24AWG)
~
300' ( 90 m)
~
300' ( 90 m)
~
300' ( 90 m)
~
70' ( 20 m)
300' ( ~ 90 m)
~
200' ( 60 m)
in.k6XX
Pos 2
Pos 1
