SAFETY CATCH FEATURE
9.
DISENGAGING AND REMOVAL OF THE MONITOR
To remove, grasp firmly on the bottom edge of the monitor, pull outward first
(9a), then upward (9b) to disengage the bottom hooks.
NOTE: A safety catch feature on the top hook will keep the monitor from
disengaging and falling forward at the top.
With the bottom hooks disengaged, ease the monitor back to a near
vertical position (9c) while dropping down slightly (9d). The top hooks
should now disengage and allow the monitor to move easily away from
the shroud (9e).
Disconnect the power cord from the receptacle and all cables
9c
from input terminals on the monitor.
BOTTOM HOOK
9d
9e
9b
9b
9a
9a
Page 8 of 24
25393001 Rev A
