Choosing Where To Place The Speakers
Speaker placement within the listening room will have a great impact upon the total performance of the unit in terms of bass performance,
tonal accuracy, and imaging. All rooms are different and so this section is intended as a guide only. Experimentation in your room will yield
optimum results.
Begin by placing the rear of the speakers approximately one to two feet in from the front walls and the sides one to two feet in from the
side walls of your listening room, as shown in Figure 1. Your listening position should be roughly equal to the distance between the two
speakers. Also, turn the speakers inward so each axis points toward the listening position.
Next, connect the audio system as described in CONNECTING THE SPEAKERS on page 8. Then, optimize the speaker placement as
described in OPTIMIZING THE SYSTEM on page 9.
Speaker care
This model is carefully finished with high-quality urethane coating. If it gets dusty or dirty, wipe it off with a soft cloth. If it is very dirty, soak
a soft cloth in a neutral detergent diluted 5 to 6 times with water, squeeze it well, wipe off the dirt and then wipe it with a dry cloth.
CAUTION
When dusting the cabinet, do not use cleansers, abrasives or chemically impregnated cloths.
Contact with alcohol, benzene, insecticides or other chemicals may cause peeling or discoloration of the finished surface.
Left
Speaker
About 12 in. to 24 in.
(305 mm to 610 mm)
A
Listening Position
(e.g., on couch)
• Make distance "A" larger than distance "B"
• Point each speaker in the listening position
Figure 1. Placement of a pair of speakers for stereo music listening
About 12 in. to 24 in.
(305 mm to 610 mm)
Right
Speaker
B
About 12 in. to 24 in.
(305 mm to 610 mm)
A
7
