Brink 4340 Instructions De Montage
Liens rapides
Fitting instructions
Make:
Toyota
Urban Cruiser
Type:
4340
Montagehandleiding
Fitting instructions
Montageanleitung
Instructions de montage
Monteringsanvisningar
Montagevejledning
Instrucciones de montaje
Istruzioni per il montaggio
Instrukcja montażu
Asennusohjeet
Pokyny k montáži
Szerelési útmutató
Руководство для монтажа
Your perfect fit
brink.eu
Manuels Connexes pour Brink 4340
Sommaire des Matières pour Brink 4340
- Page 1 Fitting instructions Make: Toyota Urban Cruiser Type: 4340 Montagehandleiding Fitting instructions Montageanleitung Instructions de montage Monteringsanvisningar Montagevejledning Instrucciones de montaje Istruzioni per il montaggio Instrukcja montażu Asennusohjeet Pokyny k montáži Szerelési útmutató Руководство для монтажа Your perfect fit brink.eu...
- Page 2 M10x1,25x40 ø30x14 L=10mm 70Nm ø30x14 L=8mm M10x35 (10.9) 65Nm ø30x14 L=10mm M10x1,25x40 70Nm ø30x14 L=8mm M12x85 (10.9) 110Nm M10x35 (10.9) 65Nm © 434070/05-06-2009/1...
- Page 3 M10x1,25x40 ø30x14 L=10mm 70Nm ø30x14 L=8mm M10x35 (10.9) 62Nm ø30x14 L=10mm M10x1,25x40 70Nm ø30x14 L=8mm M12x85 (10.9) 95Nm M10x35 (10.9) 62Nm © 434070/05-06-2009/2...
- Page 4 (6x) M10x1,25x40 (6x) M10 (2x) ø30x14 L=10mm (2x) ø24x15 L=8mm (4x) M10x35 (10.9) (4x) M10 (10) (2x) M12x85(10.9) (2x) M12 (10) Brink BMA Usermanual EC9420 CARLOS approved tested 4340 brink.eu © 434070/05-06-2009/3...
- Page 5 Couplingsclass: A50-X D-Value : euro Approved tested e11 00-7080 94/20/EC 50 kg 10.9 MODIFICATION? © 434070/05-06-2009/4...
- Page 6 * Should this installation process entail the cutting of the bumper – con- formation MUST be obtained by the installation engineer of the custo- mer’s acceptance prior to completion. Brink Towing Systems do not accept responsibility for any matters arising as a result of this miscom- munication.
- Page 7 © 434070/05-06-2009/6...
- Page 8 (3x) M10x1,25x40 (3x) M10x1,25x40 (3x) M10 (3x) M10 (1x) ø30x14 L=10mm (1x) ø30x14 L=10mm © 434070/05-06-2009/7...
- Page 9 © 434070/05-06-2009/8...
- Page 10 (4x) M10x35 (10.9) (4x) M10 (10) (2x) M12x85 (10.9) (2x) M12 (10) © 434070/05-06-2009/9...
- Page 11 © 434070/05-06-2009/10...
- Page 12 Brink BMA Usermanual EC9420 CARLOS approved tested brink.eu © 434070/05-06-2009/11...
- Page 13 Dispositivo di traino tipo: 4340 Per autoveicoli: URBAN CRUISER; 2009-> Tipo funzionale: NLP115 * - AHF * * W Classe e tipo di attacco: A50-X Omologazione: e11 00-7080 Valore D: 6.1 kN Carico Verticale max. S: 50 kg Larghezza rimorchiabile per Caravan e T.A.T.S.: 2,45m vedere CARTA di CIRCOLAZIONE VEICOLO (motrice) + 70 cm = ..arrotondare ai 5 cm superiore (vedi D.M.28/05/85)
- Page 14 © 434070/05-06-2009/13...
- Page 15 © 434070/05-06-2009/14...
