Monacor PA-1120CD Mode D'emploi page 8

the antenna screw connections while observing the
GB
lettering on the amplifier or basic unit:
AM+GND for medium wave antenna
FM 75 Ω for VHF antenna with 75 Ω connection
cable
300 Ω for VHF antenna with 300 Ω connection
cable
5 Operation
Switch on the amplifier or the basic unit with the mains
switch and the insertion with the button PWR (2). The
red power LED (1) and the display (7) light up. To
switch off, actuate the button PWR once again.
5.1 Operation of the CD player
5.1.1 Playing a CD
1) Insert a CD with the lettering facing upwards into
the CD slot (8) until it is automatically pulled in. If
there is already a CD in the unit, the display shows
the symbol
IN
2) To change a CD, press the button EJECT (6). The
CD is ejected and the display shows EJECT. (In
case of PA-1120RCD, the unit simultaneously
switches to radio reception.) If the ejected CD is not
removed, the unit will pull it in again after approx.
10 seconds.
3) After inserting a CD, the display successively
shows LOAD and PLAY. Then the total playing time
and the total number of titles on the CD is dis-
played. The first title starts and the display shows
the time already played and the title number.
4) Adjust the desired volume with the volume control
LEVEL (10).
5) At the end of the CD, the CD player starts the first
title again (continuous replay).
6) To interrupt the CD replay, press the button
PLAY/PAUSE (3). The display shows PAUSE and
all other indications extinguish.
To continue the CD replay, press the button
PLAY/PAUSE once again.
5.1.2 Title selection
1) Select the desired title with the buttons
button : upon each actuation the unit advances
one title
button : short actuation – the unit returns to the
title beginning;
upon each further short actuation of the button, the
unit reverses another title
2) The first title of the CD can be selected at any time
with the button TOP (9).
8
.
PAUSE RDM SCAN RPT
TRACK
Min. Sec. Track Display
5.1.3 Fast forward or reverse run
If the button
if the button
fast forward or reverse run also goes beyond several
titles, however, it stops at the beginning or the end of
the CD.
5.1.4 Short playing of the title beginnings
The beginnings of all titles of a CD can be shortly
played for 10 seconds each.
1) Press the button INTRO (9). The display shows
SCAN. If the currently playing title has already been
played for more than 10 seconds, the unit goes to
the next title.
2) To switch off this function, press the button INTRO
once again. SCAN extinguishes and the title that
has just been started is continued. The function is
also switched off by actuating the button TOP, RPT,
or RND (9).
5.1.5 Repeat of a title
1) Select the title to be repeated with the button
(5), then press the button RPT (9). RPT is dis-
played and the title is continuously repeated.
2) To switch off this function, press the button RPT
once again. RPT extinguishes. The function is also
switched off by actuating the button TOP, INTRO,
or RND (9).
5.1.6 Random replay
In case of random replay, the titles are not played in
ascending order but in a sequence that the unit selects
at random.
1) Press the button RND (9). RDM is displayed.
2) The unit selects the next title at random. The num-
ber of the title is indicated under TRACK. The se-
lected title starts.
IN
3) To switch off the random replay, press the button
RND once again. RDM extinguishes. The function
is also switched off by actuating the button TOP,
INTRO, or RPT (9).
5.1.7 Switching off the sound (muting)
(PA-1120CD only)
If the sound is to be switched off, press the button
MUTE (4). MUTE flashes on the display, however, the
CD is continued. By pressing the button MUTE once
again, the sound is switched on again.
and (5).
(5) is kept pressed, the unit advances,
is kept pressed, the unit reverses. The
or
