STEP 1
Loosen the four screws to remove the unit' ' ' ' ' ' ' ' ' ' ' ' ' ' ' ' ' ' ' ' ' ' s
housing.
e K
p e
e h t
u
t i n
t a
e l
t s a
floor. This minimum distance must be
maintained.
Do not install closer than 3' (0.9 m)
from a vertical surface.
STEP 2
Mark the drill-hole positions in the ceiling for
the mounting bracket.
Drill the required holes with diameter fit for
the anchor provided for positioning the
mounting bracket.
Insert the anchors.
Attach the mounting bracket to the ceiling
and secure with mounting screws.
' (2.4 m) away from the
' ' ' ' ' ' ' 8
minimum
3 feet (0.9m)
minimum
3 feet (0.9m)
8
MODEL:PH-945
