• Ensure that the collection bag is handled with care to
prevent damage and that is does not get caught or
ripped by the container deflector flange or other sharp
objects or projections.
• Insert the collection bag into the container with the
opening towards the front of the vacuum cleaner.
• Pull the collection bag opening over the container
deflector flange ensuring the collection bag opening
passes over the ridge on the container deflector.
• Ensure collection bag is pushed tight.
• Fold out the rest of the disposal collection bag
downwards into the container.
CAUTION:
Take care of the bag to ensure it does not get damaged
when fitting or when removing.
Removing the Collection Bag
-
(Fig. 4)
To remove bag undo the container hose pull bag off the
container deflector flange. Close the bag by flipping the
tab over.
Dispose of the filter in a suitable container according to
the applicable laws.
It is good practice however, to change the bag regularly
to guarantee optimal cooling of the motor.
If the vacuum cleaner is used without the paper dust bag,
it is recommended that the dust container be emptied
and cleaned after each use. this procedure is also
recommended following the suction of any type liquid.
The collection bag must be replaced when
the extraction velocity monitor goes to red and
stays on red.
Mounting the Hose, Nozzles and
-
Tubes (Fig. 5, 5a)
• Connect the hose to the container by pushing the hose
with bayonet fitting into the container hose inlet ensure
bayonet tabs are vertical and turn clockwise to lock.
To remove hose, turn hose with bayonet fitting anti-
clockwise to remove from the inlet.
• The spouts are a push fit on the extension tubes. To
remove the spouts, turn the parts in the opposite
direction and pull apart.
• For carpets use the universal spout.
• For floors, clip the brush spout insert into the universal
spout.
Fitting/Removing Cartridge Filter
-
(Fig. 6)
The filter cartridge has to be completely pushed in and
is secured by turning the butterfly nut clockwise. Check
EN - T33A
that it fits correctly. In order to remove the cartridge
filter turn the butterfly nut anti-clockwise and withdraw
the cartridge filter. Ensure the seal around the retaining
screw is in place.
Before using the appliance always check
that always check that all the filters provided
are in the correct position.
OPERATION

Starting Operation

Observe correct mains voltage! The voltage of the power
source must agree with the voltage specified on the
nameplate of the vacuum cleaner. Equipment marked
with 220-240V can also be operated with 220V. Please
refer to the HSE guidelines concerning the handling of
materials that are hazardous to one's health.
• The machine must be always kept on horizontal bases,
in a safe and stable way.
• Insert the suitable filters for the proper use.
• Never use the appliance without the filters.
• Use the most suitable accessories for the requested
usage.
The vacuum cleaner may generally not be used in rooms
where the danger of an explosion exists. To save energy,
only switch the vacuum cleaner on when using it.
Dry Vacuuming
Never use the appliance without the polyurethane foam
filter, cartridge filter or the collection bag.
• Fit the cartridge and lock in position using the butterfly
screw.
• To switch the vacuum cleaner on, press button down.
• To switch the vacuum cleaner off, press button down to
release.
If extraction velocity monitor is red, press and hold filter
shaker button for 3 seconds. (device/extraction must
be on) filter will continue shaker function for a further 5
seconds after release. If the monitor turns red only as
and when you connect to a power tool, ensure that the
extraction spouts of the tool and hose are not blocked.
If clear, it is OK to use. Check the flow periodically by
removing the extraction hose.
If red monitor continues the dust bag may be full, and
will need to be replaced. See Filter
NOTE: An adequate ventilation rate (M) must be
