MARKINGS ON TOOL
The following pictures are shown on the appliance.
Read instruction manual before use.
WARNING:
This appliance contains harmful dust. The emptying and
maintenance, including the removal of the collection
bag, may only be executed by trained personnel wearing
suitable protection equipment. Do not switch on until the
complete filter system has been installed. Otherwise
there is a danger to your own health.
Class M vacuum cleaners are suitable to vacuum dry,
non-combustible dusts with workplace limit values of ≥
0.1 mg/m .
3
WARNING:
The vacuum cleaner contains materials that are
hazardous to one's health. Have the emptying
and maintenance, including the disposal of
dust-collection containers, carried out only by
specialists.
Appropriate protective equipment is required.
Do not operate the vacuum cleaner without
the complete filter system. Otherwise there is
danger to your own health.
Date Code Position
The date code, which includes the year of manufacture,
is printed on the rating plate that can be found on the
appliance top housing.
ITEMS ENCLOSED
1 x Cartridge Filter HEPA H13
1 x No Foam Filter
2 x Castors
2 x Main Wheels
1 x Plastic Tank
1 x Synthetic Collection Bag
1 x Hose 5m x 39mm Ø with Hose Spout
2 x Extension Tubes
1 x Curved Metal Tube
1 x High Efficiency Floor Brush
1 x Hard Floor Brush
1 x Power Tool Adaptor
1 x Crevice Tool /Brush
1 x Manual
1 x Guarantee Card
EN - T33A

DESCRIPTION OF PARTS

A. Switch ON-OFF
B. Power tool socket
C. Extraction velocity monitor
D. Shaker button
E. Carrying handle
F. Cartridge filter HEPA
G. Collection bag
H. Container
I. Container hose inlet
J. Container deflector flange
K. Lid
L. Container catch
M. Castors
N. Main wheels
O. Hose bayonet fitting
P. Hose 5m x 39mmØ
Q. Extension tubes
R. Curved metal tube
S. Crevice/brush tool
T. Power tool adaptor
U. Hard Floor Brush
V. Hose spout
W. High efficiency floor brush
X. Onboard storage locations
Y. No Foam Filter
Z. Crevis Brush
• Check for damage to the tool, parts or accessories,
which may have occurred during transport. Parts and
accessories may be inside container.
• Take the time to thoroughly read and understand this
manual prior to operation.
WARNING:
Never modify the appliance or any part of it.
Damage or personal injury could result.
-
ASSEMBLY
Accessories are secured inside the container. Undo the
three container catches, remove the motor lid, remove
accessories. Turn the container upside down, insert front
castor wheels. Locate main wheels, and click to lock
into place. Turn container right way up. Fit collection
bag (see Inserting and Removing the Collection Bag
section). Ensure the cartridge filter butterfly screw is
tight. Refit motor and ensure all three container catches
are fastened.
Inserting Collection Bag
• Unlock the container catches and remove the lid.
• The collection bag has a card-reinforced opening with
a tab at the top.
-8-
-
(Fig. 1)
(Fig. 2)
-
(Fig. 3)
