Tunturi SEATED LEG EXTENSION Mode D'emploi page 7

D-3
Platinum Seated Leg Extension
F C
F
C
A B
M10 lock nut Round head screw M8X25
*8pcs *4pcs
E F
Flat washer (galvanized) Φ8 Flat head screw M10X25
*8pcs *8pcs
J K
8X25 Ordinary flat key Flat head screw M10X30
*1pc *3pcs
W
N Round head screw M8X60
Flat head screw M10X20
*4pcs
*1pc
T V
17-14 wrench 3mm hexagon wrench
*1pc *1pc
7
7
C D
Φ10 flat washer Hexagon socket head screw
*24pcs (half-thread galvanized) M10X125
*4pcs
G H
Flat head screw M10X35 Hexagon socket countersunk screws
*3pcs M10x25 *3pcs
L M
M5 hexagon socket head screw Flat washer (galvanized) Φ5
*16pcs *16pcs
X Z
5mm hexagon wrench 6mm hexagon wrench
*1pc *1pc
