Delta Dryden 751 Manuel D'installation
®
ASME A112.18.1 / CSA B125.1
ICC/ANSI A117.1
751 Model/Modelo/Modèle
Dryden™ Series/Series/Seria
Write purchased model number here.
Escriba aquí el número del modelo comprado.
Inscrivez le numéro de modèle ici.
You may need / Usted puede necesitar / Articles dont vous pouvez avoir besoin:
For easy installation of your Delta
faucet you will need:
• To READ ALL the instructions completely
before beginning.
• To READ ALL warnings, care, and maintenance
information.
• To purchase the correct water supply hook-up.
Para instalación fácil de su llave Delta
usted necesitará:
• LEER TODAS las instrucciones completamente
antes de empezar.
• LEER TODOS los avisos, cuidados, e
información de mantenimiento.
• Comprar las conexiones correctas para el
suministro de agua.
Pour installer votre robinet Delta
facilement, vous devez:
• LIRE TOUTES les instructions avant de
débuter;
• LIRE TOUS les avertissements ainsi que toutes
les instructions de nettoyage et d'entretien;
• Acheter le bon nécessaire de raccordement.
53361
U P
C
®
SINGLE HANDLE LAVATORY
VESSEL FAUCET
LLAVE DE AGUA DE RECIPIENTE PARA
LAVAMANOS DE UNA MANIJA
ROBINET À UNE MANETTE POUR
BASSIN DE COMPTOIR
53361
1
T E FLO N
11/8/08 Rev. C
