Press and hold the button for releasing the support leg. Pull the support leg out until
you reach correct vertical position.
On both sides of the seat, press the ISOFIX button and pull the ISOFIX connectors to
the longest position. Slide the two ISOFIX connectors firmly into the inserts until the
ISOFIX connectors engage with a clicking sound on both sides. The ISOFIX button
should be green on both sides (Figure A.3).
WARNING! The ISOFIX connectors are only inserted correctly if both ISOFIX buttons
are marked green.
Press the ISOFIX base tightly against the backrest. Place the car seat with the front part
opposite to the direction of movement (the baby must be in the direction opposite to
the direction of movement). Fix the seat to the ISOFIX base as shown in illustration
A.6-7 – connect the mounting bars onto the base until they lock onto thre base by
means of an audible "click".
REMOVING THE ISOFIX BASE - ILLUSTRATION A.8:
To remove the base, press the button to release the child seat from the base and lift
the seat with the handle up. The ISOFIX button on the base will be marked in red.
Unlock the ISOFIX connectors and remove the base. Press and hold the support leg
release button to retract it.
INSTRUCTIONS FOR MAINTENANCE AND CLEANING
❖ CLEANING
1. The base can be cleaned using a wet cloth. Do not use strong detergents (for
example solvents).
2.Avoid wetting the labels. Do not remove them, because they contain important
information.
Manufactured for CANGAROO in PRC
Manufacturer and Importer: CANGAROO Trade Ltd.
Address: Bulgaria, Sofia, Trebich, 1 Dolo Str.,
Phone number: 003592/936 07 90; Website:
www.moni.bg
11
