4. TECHNICAL SPECIFICATION
Product specification:
Size
Model name
Interface
Viewing area
Viewing angle
Resolution(Typ.)
Display color
Panel
Brightness(Max.)
Response time(OD)
Contrast(DCR)
Contrast (Typ.)
Type
Power
Consumption
Stand-by
VESA wall mount
Physical
Stand
Accessories
HDMI Cable, plastic stand, Manual
1. Frameless
2. Support Freesync/G-Sync function
3. Blue light filter
Feature
4. Flicker free
5. Extra low consumption on standby mode 0.5w
6.IPS panel
12
Spec.
23.8''
D24IP75B / VALI
VGA + HDMI + SPK + DC
527.04(H)×296.46(V) mm2
H:178°V:178°
1920x1080 @75Hz
16.7M
250cd/m2
14ms
10,000,000 : 1
1,000:1
DC 12V/2.5A
<25W
<0.5W
75 x75 mm(4 holes)
Tilt : -5 ~ 15°
5. TROUBLE SHOOTING
If your monitor cannot work normally, please refer to the follow methods for
common problems quickly, if you need assistance; please call the dealer where
you purchased the Monitor.
A. There is no Screen Image and no lights
Please check to see whether the power cord is securely connect to the monitor
and wall outlet, and whether the display is in power saving mode.
B. There is no Screen Image and the light is red
Please to see whether the display card of PC is loosed, and check the
connection between signal cables and display.
C. The display is not clear or the image is too large or too small
Enter the OSD image adjustment menu, and then select "Auto Adjust" to
make the display to adjust automatically to optimum.
D. The image is too light or too dark
Enter the OSD brightness adjustment menu, and then select the "Up/Down"
to adjust the brightness and contrast to optimum.
E. The screen is overheated
Please keep at least 5cm all around the display for ventilation, and do not
place anything onto the monitor.
F. Dark display when booting
The monitor needs a little bit of time to adjust the lighting and colors due to
temperature difference.
G. The image is distorted, flashes and shakes
Check the settings of the computer and choose the proper resolution.
H. The color is abnormal
Check the connection of signal cable, if there is any curved or broken pin,
please replace it; Enter the OSD color adjustment menu to set the display
color to the optimum.
