One-year standard tool warranty
Should your Tacwise air tool become defective due to faulty materials or workmanship within 12 months from the date of purchase, we guarantee to replace all
defective parts free of charge or at our discretion, replace the tool entirely. However, this one-year warranty does not cover any consumable parts such as
drivers, O-rings, springs etc.
6-month standard consumable parts warranty
Tacwise air tools are warranted to be free from defects with all its original consumable parts for 6-months from the date of purchase.
Neither of these warranties cover:
• Tools that have received unauthorised changes or additions.
• Defects caused by using accessories, components or spare parts other than approved/genuine Tacwise accessories or parts.
• Component parts that are subject to natural wear and tear caused by use in accordance with our operating instructions.
• Defects to the tool caused by improper use, abnormal environmental conditions or inappropriate operating conditions, non-compliance with our operating
instructions or insufficient servicing or maintenance.
• Proof of purchase must be produced with an original receipt.
Operating Instructions
Technical data
Characteristics
Model
Nail type
Nail length range
Magazine capacity
Minimum operating air pressure
Maximum operating air pressure
Air inlet
Air consumption
Weight
Vibration emission level*
* The declared vibration emission level represents the main applications of the tool. However if the tool is used for different applications, with different
accessories or poorly maintained, the vibration emission may differ. This may significantly increase exposure level over the total working period.
CE – Declaration of Conformity
HCN65P
Tacwise declares that this power tool has been designed in compliance with the Regulations and Standards of the European Directives.
Quality Department, Tacwise Group Plc – UK
Features (Fig. A)
1. Firing mode selector
2. Trigger
3. Quick release plug (Euro fitting)
4. Magazine drum
5. Depth adjustment wheel
6. Magazine release latch
7. Air deflector
Set up
Your air tool is fully assembled when you receive it. Before using it, attach the air line and desired air system accessories. See Fig. B for the recommended
accessories and connection order. Be sure the air hose is de-pressurised when installing or removing adaptors to the air line.
Connecting the tool to an air supply (Fig. B)
• Determine if the tool needs oil and, if necessary, place two drops of oil in the air plug as shown in Fig. B. If you are using an automatic in-line oiler, check and
add oil if necessary.
• Turn the compressor on and set the regulator to the proper pressure for the size and type of fastener being used.
• Connect the tool to the air supply.
Loading the fasteners (Fig. C)
• Depress the magazine release latch to open the nail guide door, then rotate the magazine cover so it is fully open.
• The magazine contains an adjustable nail platform (or plate) on which the nail coil sits.
NOTE: The adjustable nail platform must be set for the length of the nails used. Nails will not feed smoothly if the platform is not correctly set.
• The nail platform can be moved up and down across various settings. To adjust the nail platform, pull up and twist the platform post until the correct height is
met.
• Place the coil with points down over the platform post inside the magazine.
• Uncoil enough nails to reach the nose of the tool.
• Insert the first nail into the nose and the second nail between the two rails of the feed pawl. Ensure the nail heads are positioned in the uppermost channel of
the nose.
NOTE: Be careful not to deform the coil of nails during the loading process. Otherwise, the nail guide door will not close, and the nails might not feed
consistently.
• Close the magazine cover, then close the latch door. Make sure the door latch is completely engaged.
Adjusting the depth (Fig. D)
The driving depth of the fasteners can be set with the depth adjustment wheel.
• Fasteners are not driven in deep enough: To increase the driving depth, turn depth adjustment wheel to the left.
FASTENING TOOLS FOR THE PROFESSIONAL
Value
HCN65P
Tacwise 2.3 – 2.9 flat coil nails
32mm (1 1/4") – 65mm (2 9/16")
300
70psi / 4.82 bar
120psi / 8.27 bar
1/4" NPT
3.2 CFM @ 90psi / 6.20 bar
2.5kg (5.6lbs)
2.9m/s
2
7
