• Always remove plug from outlet before servicing your grill.
• Make sure your grill and griddle have fully cooled before moving or handling to avoid burns.
• Some components may have sharp edges. Use caution to avoid injury.
• Do NOT use griddle without the heat shields.
• Do NOT add frozen food to hot griddle.
• Do NOT remove your griddle from your grill while hot.
• Use extreme caution when seasoning and cleaning your griddle. Griddle can be extremely hot.
ACTUAL GRILL MAY DIFFER FROM ILLUSTRATIONS SHOWN.
1
Remove the warming racks and grates.
4
GRILL GRATE SUPPORT
GRILL GRATE SUPPORT
The griddle is supported by the grill grate
supports.
Griddle Instruction Sheet
1050 & 1150 GRIDDLE
CAUTION
2
BACK
HEAT SHIELD
Place the front and back heat shields into the
manifold. Install the shield support on the back
heat shield. Pull together and attach the shield
support to the front heat shield.
Do one side at a time.
5
Install the griddle by positioning it on top
of the grate supports. Griddle locator tabs should
contact the inner left wall.
3
SHIELD
SUPPORT
FRONT
HEAT SHIELD
MANIFOLD
Position the heat shields so they are angled on
opposite sides of the manifold. The shields angle is
6
GRIDDLE
GRIDDLE LOCATOR TABS
Instruction Sheet Code: 9818210002 240814-GH
HEAT SHIELD SUPPORTS
HEAT SHIELD POSITION
supported by the heat shield supports.
Install is complete.
