Simons Voss Technologies SmartHandle AX Advanced Metal frame Guide Abrégé page 36

9. Technical data
14. Put the battery module back into the module support.
69
15. Use the special tool to reattach the battery module clip.
70
9 SmartHandle AX Advanced will beep three times.
16. Place the cover on top of the fastening plate.
71
17. Fold down the cover.
72
18. Push the cover against the door, sliding it upwards at the same time.
73
Cover snaps into place.
9
19. Press the inlay into place.
74
9 Batteries are now replaced.
9. Technical data
Operating temperature range
Battery type
Battery manufacturer
IP protection rating
Radio emissions
15.24 kHz - 72.03 kHz
Only for item numbers: SV-
S3.*AM.G2*, SV-S3.*A.G2*, SI-
S3.*LN*
13.560006 MHz - 13.560780 MHz
Only for item numbers: SV-
S3.*AM.G2*, SV-S3.*A.G2*, SI-
S3.*M.WO*, SI-S3.*LN*, SI-
S3.*OSS*
868.000 MHz - 868.600 MHz /
869.700 MHz - 870.000 MHz
Only for item numbers: SI-
S3.*M.WO*, SI-S3.*LN*
2402 MHz - 2480 MHz
Only for item numbers: SV-
S3.*AM.G2*, SV-S3.*A.G2*, SI-
S3.*M.WO*, SI-S3.*LN*, SI-
S3.*OSS*
10. Declaration of conformity
The company SimonsVoss Technologies GmbH hereby declares that the
articles (SI-S3.*M.VCN*, SV-S3.*M.G2*, SV-S3.*AM.G2*, SV-S3.*A.G2*, SI-
S3.*M.WO*, SI-S3.*LN*, SI-S3.*OSS*) comply with the following guidelines:
 2014/53/EU -RED-
or for the UK: UK statutory 2017 No. 1206 -Radio equipment-
2011/65/EU -RoHS-

or for the UK: UK statutory 2012 No. 3032 -RoHS-
The full text of the EU Declaration of conformity is available at the following
www.simons-voss.com/en/certificates.html
internet address:
The full text of the UK Declaration of conformity is available at the following
www.simons-voss.com/en/certificates.html
internet address:
36 / 60
-25 °C to +60 °C
4x CR2450 3V lithium
Duracell

Murata

Panasonic

Up to IP66 (WP variant)
10 dBµA/m (3 m distance)
1.04 dBµA/m (3 m distance)
<25 mW ERP
2.5 mW
.
.
SmartHandle AX Advanced Metal frame
11. Help and other information
Information material/documents
https://www.simons-voss.com/en/documents.html
https://www.smartintego.com/int/home/infocenter/documentation
Declarations of conformity
https://www.simons-voss.com/en/certificates.html
Information on disposal
 Do not dispose the device (SI-S3.*M.VCN*, SV-S3.*M.G2*, SV-
S3.*AM.G2*, SV-S3.*A.G2*, SI-S3.*M.WO*, SI-S3.*LN*, SI-S3.*OSS*)
in the household waste. Dispose of it at a collection point for electronic
waste as per European Directive 2012/19/EU.
Recycle defective or used batteries in line with European Directive

2006/66/EC.
 Observe local regulations on separate disposal of batteries.
 Take the packaging to an environmentally responsible recycling point.
75
Technical support
+49 (0) 89 / 99 228 333
Email
support-simonsvoss@allegion.com
si-support-simonsvoss@allegion.com
FAQs
https://faq.simons-voss.com/otrs/public.pl
SimonsVoss Technologies GmbH, Feringastr. 4, D-85774 Unterfoehring,
Germany
