STAINLESS STEEL LOW BACK PRESSURE REGULATOR
Description
The diaphragm back pressure regulator protects compressed air devices from excessive pressure.
If the pressure setpoint is exceeded, overpressure is vented into the atmosphere until the setpoint is
reached again. It is recommended to choose a pressure range as low as possible.
Media
compressed air, gases
Adjustment
by adjusting screw for D3100-02 to - 1A, with locknut
by T-handle for D3100-12 and -16, with locknut
Gauge port
G¼ on both sides of the body, screw plugs supplied
Temperature range
0 °C to 80 °C / 32 °F to 176 °F, FKM or EPDM
0 °C to 130 °C / 32 °F to 266 °F, high temperature version
for appropriately conditioned compressed air down to -20 °C / -4 °F
or low temperature version down to -40 °C / -40 °F
Material
Body:
stainless steel 316L, material no. 1.4404
Diaphragm: NBR/Buna-N with PTFE coating
Inner valve: stainless steel 316L, material no. 1.4404
Dimensions
Exhaust
A
B
C
rate
mm
mm
mm
l/min*
1
Back pressure regulator
265
290
45
2 000
4 100
5 000
265
290
45
2 000
4 100
5 000
171
460
128
2 500
5 000
7 500
171
420
128
10 000
171
460
128
2 500
5 000
7 500
171
420
128
10 000
D3100-10/-1A
at 6 bar overpressure and open outlet
*
1
B6 = 0...60 mbar, C3 = 0...250 mbar
*
2
Gauges: see chapter for measuring devices
System pressure
Mounting position any
O-rings:
Over-
Connection
Adjustment
pressure
thread
range
max. bar
G
mbar
overpressure max. 6 / 10 bar,
PTFE-diaphragm and FKM-o-ring
6
G1¼
0 ... 300
0 ... 700
0 ... 1 200
6
G11/2
0 ... 300
0 ... 700
0 ... 1 200
6
G11/2
20 ...
50 ... 150
150 ... 300
300 ... 3 000
6
G2
20 ...
50 ... 150
150 ... 300
300 ... 3 000
D3100-12/-16
max. 10 bar (see table)
FKM, optionally EPDM
Order
Price
number
C
€
D3100
D3100-10BT
1.630,00
D3100-10CT
1.630,00
D3100-10DT
1.630,00
D3100-1ABT
1.630,00
D3100-1ACT
1.630,00
D3100-1ADT
1.630,00
50
D3100-12AT
3.310,00
D3100-12BT
3.310,00
D3100-12CT
3.310,00
D3100-12DT
3.310,00
50
D3100-16AT
3.310,00
D3100-16BT
3.310,00
D3100-16CT
3.310,00
D3100-16DT
3.310,00
D3100
G1/4 and G2
0 ... 45 / 3 000 mbar
D3100-10/-1A
D3100-12/-16
Order example:
D3100-10BT
15.27
SST
15
