The diaphragm back pressure regulator protects compressed air devices from excessive pressure.
If the pressure setpoint is exceeded, overpressure is vented into the atmosphere until the setpoint is
reached again. It is recommended to choose a pressure range as low as possible.
Media
compressed air, gases
Adjustment
by adjusting screw for D3100-02 to - 1A, with locknut
by T-handle for D3100-12 and -16, with locknut
Gauge port
G1/4 on both sides of the body, screw plugs supplied
Temperature range
0 °C to 80 °C / 32 °F to 176 °F, FKM or EPDM
0 °C to 130 °C / 32 °F to 266 °F, high temperature version
for appropriately conditioned compressed air down to -20 °C / -4 °F
or low temperature version down to -40 °C / -40 °F
Material
Body:
Diaphragm: NBR/Buna-N with PTFE coating
Inner valve: stainless steel 316L, material no. 1.4404
Dimensions
A
B
C
mm
mm
mm
Back pressure regulator
109
181
39
109
181
39
109
181
39
SST
161
290
45
15
161
290
45
D3100-02/-03/-04
at 6 bar overpressure and open outlet
*
1
B6 = 0...60 mbar, C3 = 0...250 mbar
*
2
Gauges: see chapter for measuring devices
15.26
STAINLESS STEEL LOW BACK PRESSURE REGULATOR
stainless steel 316L, material no. 1.4404
Exhaust
Over-
Connection
rate
pressure
thread
l/min*
max. bar
G
1
overpressure max. 6 / 10 bar,
PTFE-diaphragm and FKM-o-ring
450
10
G1/4
750
1 000
1 400
450
10
G
750
1 000
1 400
450
10
G1/2
750
1 000
1 400
1 500
6
G3/4
2 300
3 000
1 500
6
G1
2 300
3 000
gauge G1/4
System pressure
max. 10 bar (see table)
Mounting position any
O-rings:
FKM, optionally EPDM
Adjustment
Order
range
number
mbar
D3100
D3100-02AT
0 ...
45
0 ... 400
D3100-02BT
D3100-02CT
0 ... 1 000
0 ... 1 500
D3100-02DT
/
0 ...
45
D3100-03AT
3
8
0 ... 400
D3100-03BT
0 ... 1 000
D3100-03CT
D3100-03DT
0 ... 1 500
0 ...
45
D3100-04AT
D3100-04BT
0 ... 400
0 ... 1 000
D3100-04CT
0 ... 1 500
D3100-04DT
0 ... 300
D3100-06BT
0 ... 700
D3100-06CT
D3100-06DT
0 ... 1 200
0 ... 300
D3100-08BT
D3100-08CT
0 ... 700
0 ... 1 200
D3100-08DT
D3100-06/-08
G1/4 and G2
0 ... 45 / 3 000 mbar
Price
C
€
895,00
895,00
895,00
895,00
895,00
895,00
D3100-02 / -03 / -04
895,00
895,00
895,00
895,00
895,00
895,00
1.630,00
1.630,00
1.630,00
1.630,00
1.630,00
D3100-06/-08
1.630,00
Product group
Order example:
D3100-02AT
D3100
