DisplayLink™ Manager Menu
Menu Option
DisplayLink Manager
Opens the Screen Resolution window
Check for Updates
Checks online if new drivers are available to download
DisplayLink devices
Shows a list of all connected DisplayLink devices
Audio Setup
Opens the Audio Configuration window
Video Setup
Opens the Screen Resolution window
Shows a list of all available screen resolutions. Inferred Modes [ ] are not
Screen Resolution
available in mirror mode
Screen Rotation
Rotates the screen in clockwise or counter-clockwise directions
Extend
Extends the Windows desktop onto this display
Set as Main Monitor
Sets this screen as the main display
Switches off the laptop display and use the DisplayLink display as the
Notebook Monitor
main screen (only works on PCs and when only one DisplayLink screen
Off
is connected)
Shows the same content on both screens (screen resolutions must be
Mirror
the same)
Off
Turns off this DisplayLink display
Select for improved video playback on DisplayLink connected displays
Optimize for Video
(only applicable for video; text may appear less clear)
Adjusts the size of the Windows desktop to fit the connected TV (only
Fit to TV
works when one DisplayLink display is connected and set in Extend
Mode)
To Set the Display into
Extend Mode
1. Click on the DisplayLink icon
.
2. Select Extend in Manager Menu.
The device is now extended in the direction it was
the last time the display was in this mode. For more
control, use the Extend To submenu and select one
of the options. This puts the device into Extend Mode,
and places it to the Left/Right/Above/Below the main
monitor.
To Set the Display into
Mirror Mode
1. Click on the DisplayLink icon
.
2. Select Mirror in Manager Menu.
The resolution, color depth and refresh rate of the
primary screen are replicated on the monitorconnected
to the docking station.
Fit to TV Configuration
1. To configure Fit to TV, choose the option from the
DisplayLink Manager. The following interface appears.
2. You will also see a red border on the DisplayLink
screen.
The red border shows the size of the new Windows-
Desktop. Use the "+" and "-" controls to change the size
of the red border until it fits on the TV screen.
3. Once the red border is at the edges of the TV screen,
click "Apply" to resize the Windows desktop.
5
