ASSEMBLY GUIDE
Preparing for Power Supply Column Swap
Install the Service Hatch back
onto the Desk Frame using the
Screwdriver Handle and small end
of the Double-End Bit provided.
Remove the cardboard covers.
Swapping the Motorized Leg Columns
Swap the Motorized Leg Columns
to the opposite sides. Plug the
cables on the Motorized Leg
Columns to the corresponding
cables shown in the diagram to
connect them to the Control Box.
Yellow-to-Yellow
Push Red into Frame
Right Motorized Leg Column
Left Motorized Leg Column
Desk Frame
Blue-to-Red
Yellow-to-Yellow
TOOLS
PROVIDED
2
