NANO Proximity Reader -
Wiegand
The NANO from CDVI is a mini and compact
proximity card reader.
These stylish new readers are available in both
black and white. As with the other readers
from the range (STAR, SOLAR and MOONAR),
the NANO gives an anytime status of the door
through multi-coloured LED's.
These access control readers have a high
performance read range and are easy to mount.
We, CDVI, declare that the NANO radio equipment complies
with directive 2014/53/UE. The full text of the EU declaration is
available at www.cdvi.com
• Wiegand 26, 30 or 44-bit
• Audible and visual feedback
• Reads CDVI 125 kHz cards and tags
• Up to 4 in. (10 cm) read range
• Power requirements: 12V DC
• Current consumption: 150 mA
• Multicoloured LED:
- Blue: Standby
- Green: Access Granted
- Red : Access Denied
RFID Frequency band: 125 kHz. Maximum transmitted power below the allowed limit: <60dBμA/m
QUICK START
INSTALLATION GUIDE
RED Certification
CE Certification
Vibrations
-25°C to +70°C
IP53
IK10
WEEE
NANOPB
43
43
43
10
10
YEAR
YEAR
WARRANTY
WARRANTY
NANOPW
23
23
