PARTS LIST
ITEM
DESCRIPTION
1
Wood Dowels Ø7.8 x 30 mm
2
Cam Bolts (big)
3
Cams (big)
4
Wood Dowels Ø5.8 x 30 mm
5
Cam Bolts (small)
6
Cams (small)
7
Extension Slides
8
Extension Rails With Stopper
9
Handles
10
Hinges
11
Handles
12
Screws Ø3.5 x 12 mm
13
Screws Ø4 x 14 mm
14
Screws Ø4 x 35 mm
15
Hexagon wrench
16
Screws Ø5 x 50 mm
17
Screws Ø3.8 x 35 mm
18
Bolts M4 x 12 mm
19
Bolts M4 x 4 mm
20
Shelf support
21
Hooks
22
Bolts M4 x 20 mm
23
Pads
Bolt M6 30 mm
24
25
Flat Washer
26
Glue
OLSEN KITCHEN ISLAND WITH LEAF
6
EXPLODED VIEW
QUANTITY
34
30
30
4
8
8
4
4
2
3
2
24
18
3
1
13
8
4
4
12
3
3
4
2
2
3
11
1
12
2
13
3
14
4
15
5
16
6
7
17
8
18
19
9
20
10
OLSEN KITCHEN ISLAND WITH LEAF
21
22
23
24
25
26
7
