SCOPE OF DELIVERY

Check the delivery for completeness and perfect condition.
In the case of missing parts or damage:
• do not mount the unit!
• do not put the unit into operation!
• make a complaint to the supplier.
The deliver consists of:
• Product
• Instructions

TECHNICAL DATA

• These products contain a light source of energy efficiency class E
• Illuminant: SMD LED´s
• Colour temperature: 6500K
• Ra/CRI: ≥ 80
• LED service life: 25000h
• Beam angle: 120°
• IP protection class: IP44
• Protection class: II (S7)
• Ambient temperature: -10°C – 35°C
• Continuous operation possible
Type Nominal values
PK-CL-B-05B 230V~; 50Hz; 0,046A
PK-CL-B-10B 230V~; 50Hz; 0,087A
INSTALLATION
• ATTENTION!! Before installation, the power supply must be disconnected from the mains and secured against
being switched on again (S4).
• Please refer to the drawings for the installation steps.
• Use a wire cross-section of at least 0.75mm² - max. 1.5mm² for connection.
• Do not connect the lamp to a dimmer.
CLEANING
• Disconnect the product from the power supply and secure the circuit from being switched on again.
• Allow the luminaire to cool down sufficiently!
• Clean with a dry or slightly moist, clean, lint-free cloth and a mild detergent if required. Do not use cleaners that
contain abrasives or solvents.
MAINTENANCE
• Replace any damaged protective panels immediately (S8).
• Remove all dirt from the housing or protective panel immediately, as this can lead to overheating.
• The light source of this luminaire is not replaceable; if the light source has reached the end of its service life, the
entire luminaire must be replaced.
All manuals and user guides at all-guides.com
Performance
5,5W
10W
LED LED
Light source not
1
interchangeable!
Luminous flux
450lm
800lm
1
Control gear not interchangeable
2
(ballasts, power supply units, etc.)!
GB
Luminous efficacy
82lm/W
80lm/W
2
