CHARGER INSTRUCTIONS
Pull the spring plate in the charger back and place the battery as shown on
1.
the sticker by paying attention to the (+) / (-) poles.
The charger will automatically regulate the current and voltage of the
2.
battery. When charging, the signal light on the charger will be red and
when the charging is over, it will become green.
You can charge 3,7V 14500-type and 1,2V AA-type batteries with this charger.
3.
INSTALLATION INSTRUCTION
1. Dismantle the cover with the colored button at the back by twisting it
counter-clockwis.
2. Place a AA- (1,5V) or 14500-type (3,7 V) Li-ion rechargeable battery. The (+)
pole of the battery should be on the lens-side.
