Display
Meaning
Battery pack
Remaining charging time of the
charging
battery pack during charging.
The battery pack is fully charged. Figure D
Fault display The battery pack temperature lies
outside the permissible tempera-
ture range or the battery pack is
disabled due to a short circuit.
Battery pack is defective and disa-
bled for safety. Do not use the bat-
tery pack and dispose of it
properly.
For the illustrations, refer
to the graphics page
Figure C
Figure E
Figure F
