Disconnect the internal components
1. Remove the protective cover
protective cover to remove it.
1
2. Remove the gas supply hose
push-to-disconnect fitting on the right
side of the solenoid valve.
3. Remove the looped gas supply hose
from the push-to-disconnect fitting on the
air filter.
4. Move the ground clip
panel. Keep the ground wire connected to the
ground clip.
Powermax45 XP Field Service Bulletin
from the rear panel. Push on the tabs
1
from the
3
4
4
off of the rear
5
809940
Machine Interface Receptacle with Voltage Divider Board
on the inside of the
2
5
2
3
