appears on the LCD.
A message will then confi rm the connection with the control unit by indicating the type of the control unit,
its version as well as the time and current date.
Press
and then enter the control unit's password: 0000 (by default). Validate with
Menu ADMINISTRATION
How to update Time/Date?
To set the current time and date in the control unit you need to check that the time and date in the terminal
is correct: the terminal information is transferred to the control unit.
Go to Administration
Press
.
And then Press
once again.
A message will indicate "Update Date/Hour OK".
How to modify a password?
Go to "Administration".
Press
.
Press
until you reach "Modifi cation Password unit?" then Press
The message "First enter" appears here, you must enter your password
The message "Confi rmation" appears here you must enter your password again.
The message "Update Password Ok" appears
Menu PARAMETERS
Go to "Parameters".
Press
.
The message"Upload PARAM OK" appears, it means that the data (doors, Call module information...) has been
downloaded successfully from the control unit to the terminal.
Validate by pressing
.
When setting the parameters, you need to be in connected mode. The terminal must remain in communication
mode with the proximity reader.
Modifi cation of the door's parameters:
Two parameters can be modifi ed through the terminal, "Modifi cation DOOR DELAY?" or "MODIFICATION FREE
ACCESS"
"Modifi cation DOOR DELAY(door time release)?"
Press
.
Set the number of seconds you want the lock to remain open.
"MODIFICATION FREE ACCESS"
Press
.
Press
to say YES and
if you want to modify the data.
Then you can set for each day the free access time periods (3 time frames per days).
BEFORE CLOSING THIS MENU YOU HAVE TO UPLOAD THE MODIFCATIONS FROM THE TERMINAL TO THE
CONTROL UNIT
When the message"UPLOAD PARAM to the unit?" appears, press
again then the message "Upload OK" appears.
Menu MAINTENANCE
The menu maintenance displays the versions of the control unit's fi rmware, reader and terminal.
This information can be useful for quality follow up.
TOKENS
Here, you can only display or suspend resident tokens
6
.
.
enter the control unit password and Press
DS90355-017
Go to "TOKENS".
Press
.
Then the message"Search by name" appears, then Press
Susp.=1" you can then valid or suspend this token
You can also search tokens by serial number
In Menu TOKENS, press
and then Press
BEFORE CLOSING THIS MENU YOU HAVE TO UPLOAD THE MODIFCATIONS FROM THE TERMINAL TO THE
CONTROL UNIT
When the message"UPLOAD TOKEN to the unit?" appears Press
then "Upload OK" appears.
HOW TO USE THE TERMINAL WITH A PROXIMAN AV0151/009 CONTROL
UNIT
Same as for Proximan AV0151/005 -/006 except for "Menu Tokens".
Menu TOKENS
Go to "TOKENS".
Press
.
Then with
you can select:
- Add token master
- Upload token to the unit
- Delete all tokens
- Delete token user
- Delete token master
- Add token user
If you want to "Add token master" or "Add token user" put a token on the keypad of the terminal...LCD will
then display the following message "Token in memory F4....." Press
Then Press
up to reach "Upload Token to the unit" and then Press
Enter Unit Password and Press
.
If you want to "Delete Token user" or Delete Token Master" select with
Press
.
Then Press X move with
up to "Upload Token to the unit" and then Press
Enter Unit Password and Press
.
INFRA RED USE
With the handheld terminal, you can change the names of an
electronic repertory call module.
To connect to the call module, you must align the IR with the IR
hole of the call module, look on the display of the call module to
see the modifi cations.
Start programming:
Press
, enter the terminal password, then select "Ext. Connect. Via Infra Red"
You will see on the display "GSM Keyboard IR".
You can use the keypad like a GSM , it takes 1/2 sec to transmit the information from Terminal to the call
module. During the process you have to double check on the terminal and Call module display to be sure that
everything is ok.
For more details about Call Module programming please refers to Call modules documentations.
DS90355-017
until you reach the "Enable=0
up to the message "Search by serial number" then, press
enter the control unit password and Press
.
.
the one you want to cancel and
.
.
IR
7
