Illustration
Connect high pressure hose to trigger
gun.
Push the clamp in until it locks. Check
the secure connection by pulling on the
high-pressure hose.
Water supply
Note: Impurities in the water can damage
the high-pressure pump and accessories.
For protection, the use of the KÄRCHER
water filter (optional accessory, order no.
4.730-059) is recommended.
Water supply from mains
Observe regulations of water supplier.
For connection values, see type plate/tech-
nical data.
Caution
Garden hose (not included) must be at
least 1/2 inch or 5/8 inch in diameter, mini-
mum length 7.5 m.
Illustration
1 Screw the supplied coupling element to
unit's water inlet.
2 Screw the supplied garden hose con-
nector on to the end of your garden
hose.
3 Push the garden hose connector on to
the water inlet connector and make
sure you hear it click into place before
proceeding.
Connect garden hose to the cold water
source and turn water on completely.
Start up
Caution
Dry runs lasting longer than two minutes
lead to damages to the high pressure
pump. If the appliance does not build up
pressure within two minutes, switch it off
and proceed as instructed in the Chapter
"Troubleshooting".
Connect the high pressure hose to the
high pressure connection of the appli-
ance.
Push the spray lance into the trigger gun
and fasten it by turning it through 90°.
Completely open the water tap.
Insert the mains plug into the socket.
Turn on the appliance "I/ON".
Operation
Danger
The trigger gun is subjected to a recoil force
when the water jet is discharged. Make
sure that you have a firm footing and are
also holding the trigger gun and spray lance
firmly.
Unlock the lever on the trigger gun.
Pull on the lever of the trigger gun; the
device will switch on.
Note: Release the lever of the trigger gun;
the device will switch off again. High pres-
sure remains in the system.
Spray lance with high pressure nozzle
For normal cleaning tasks.
Not suitable for use with detergents.
Spray lance with Dirtblaster
For particularly dirty items or areas.
Not suitable for use with detergents.
Working with detergent
Please use exclusively KÄRCHER deter-
gents and care products to carry out the re-
spective cleaning task, as these were
specifically developed for your appliance.
The use of other detergents and care prod-
ucts may lead to premature wear and can
invalidate your warranty claims. Please ob-
tain information at your local dealer or re-
quest information directly from KÄRCHER.
Pull detergent suction hose as far as is
required out of the housing.
Suspend end of detergent suction hose
in a container filled with detergent.
Detach spray lance from the trigger
gun. Work only with the trigger gun.
Note: This will mix the detergent with
the water stream.
Recommended cleaning method
Spray the detergent sparingly on the
dry surface and allow it to react, but not
to dry.
Spray off loosened dirt with the high-
pressure jet.
English 13
