TOOL AND FASTENER SPECIFICATIONS
TOOL SPECIFICATIONS
MODEL NO.
HEIGHT
WIDTH
LENGTH
WEIGHT
OPERATING PRESSURE
MAGAZINE TYPE
FASTENER SPECIFICATIONS
NAIL LENGTH
SHANK DIAMETER
NAIL COATINGS
TOOL AIR FITTINGS
This tool uses a 1/4" N.P.T. male plug. The fitting must be capable of discharging
tool air pressure when disconnected from the air supply.
OPERATING AIR PRESSURE:
90 to120 psi (6.2 to 8.3 bar). Select the operating air pressure within this range
for best tool performance.
DO NOT EXCEED THIS RECOMMENDED OPERATING PRESSURE.
PF150S-PP (Part# 502300)
11.7"
3.7"
17.4"
6 lbs. 5 oz.
90 to 120 psi (6.2 to 8.3 bar)
30 Degree, Strip
1-1/2"
.131-.148
Heat Treated,
Galvanized Heat Treated
:
3
