Uline H-2449 Mode D'emploi

H-2449
GARMENT STORAGE
CENTER WITH SHELVES
TOOL NEEDED
Rubber Mallet
(optional)
Shelf Support (52 Sets)
Self-leveler x 8
POST ASSEMBLY
1. Connect tall post tops and tall post bottoms to each
other by screwing them together. (See Figure 1)
NOTE: Tall post tops have a black plastic cap in
the top of the post.
Figure 1
TO INSTALL SELF-LEVELERS
NOTE: If installing casters, do not install self-levelers.
1. Make sure post is positioned as shown. (See Figure 2)
Figure 2
PAGE 1 OF 9
1-800-295-5510
uline.com
18 x 18" Shelf x 12
Tall Post Top with Tall Post Bottom x 6
Connector x 6
ASSEMBLY
PARTS
Short Post x 2
2. Insert self-leveler into open end of post. Use a rubber
mallet/hammer or tap on ground to slide self-leveler
into post.
3. Repeat step 2 for all other posts.
TO INSTALL OPTIONAL CASTERS
1. Make sure post is positioned as shown. (See Figure 3)
2. Engage the wheel brakes to keep casters from
rolling during assembly. Use a rubber mallet to tap
caster stem into posts. (See Figure 3)
Figure 3
Para Español, vea páginas 4-6.
Pour le français, consulter les pages 7-9.
36 x 18" Shelf x 1
Garment Rod x 1
Garment Rod Hanger x 2
1224 IH-2449
