USING THE HEATER
TEMPERATURE SETTING
1) Operate the Heating Mode as per above instructions.
2) The LED screen will display the room temperature, to adjust the temperature, press
"+" to increase the desired temperature and "-" to decrease the desired temperature.
3) When the air temperature reaches 1 degree above the set temperature, the heater
will cut off. The heater stops working but the fan continues working to allow the
product to cool down and maintain the temperature.
4) When the air temperature drops 3 degrees below the set temperature, the unit will
come back on.
5) Temperature can be set from 10 degrees to 49 degrees, by pressing the "+" and "-".
SAFETY FEATURES
A thermal overload protector is built into the heater to automatically shut the heater off if
it becomes overheated. The heater must cool down and be reset before it will operate
again. To reset, turn the Main Power Switch button to Off and then back ON. Press the
button on the control panel to resume normal operation. Be sure that the heater is on a
smooth level surface with no obstructions. The heater is also equipped with a safety tip-
over switch to turn power off to the heater when the heater tip over. To resume heater
functions simply stand heater upright. With tip over protection, the heater will only
operate when placed upright on a level surface.
REMOTE CONTROL
The remote control uses on button cell battery, type CR2025(3V).To remove the battery
carriage use your thumb to squeeze the release tab to the right and then pull the
carriage out. Place the battery into the carriage and slide the carriage back into the
remote. See Fig.4. We recommend the use of a Lithium-ion battery for longer use.
NOTE: Follow battery disposal instruction on battery packaging, or contact your local
safety council for safely disposal of batteries.
Before using the remote control, you must remove the insulating film as shown in the
figure below.
1. All functions performed with remote control work identically to the heater control
panel.
2. Aim the remote control at the heater control panel to operate the heater.
SPECIFICATIONS
Model No
820-249V81
Voltage
120V AC
Frequency
60Hz
Output Power (W)
1500W
Fig. 4
4
EN
