STRATA_HEAT Programmable Thermostat
™
TECHNICAL SPECIFICATIONS
Supply Voltage
Maximum Switch Load
GFCI
Temperature Display Range +32
Operating Temperature
Storage Temperature
Dimensions
Floor Sensor Type
GROUND FAULT CIRCUIT INTERRUPTER (GFCI)
GFCI Notice
The GFCI feature is used to detect any leakage of current from your
heating system. During a ground fault the two lines of the load will be
cut off. Once your thermostat is installed and connected to a power
supply you can test the GFCI function by increasing the set temperature
until heating is on - the heating up icon( ) will be illuminated - and
pressing the "TEST" button. If your test is successful you will see the
GROUND FAULT screen and you will need to hold "cancel" for 3 seconds
in order to restore heating operation.
However if the thermostat detects that one of the relays has FAILED to
open correctly you will see the CONTROL FAULT screen and the TEST LED
will illuminate. In the following circumstances you should immediately
isolate the power supply to the thermostat and contact LATICRETE
customer service:
1. Press the TEST button when heating is on (the heating up icon( )
will be illuminated) and the screen does not display GROUND FAULT or
cut power to the load.
2. The thermostat shows the GROUND FAULT screen during normal
operation.
3. The thermostat shows the CONTROL FAULT screen.
Note: The GFCI test should be carried out monthly.
120-240V, AC +10% / -15%, 60Hz
15A
Note: This product is not designed to be used
with any inductive load
Class A GFCI with 5mA trip level
° ° ° °
F to 122 F (0 C to +50 C)
° ° ° °
+32 F to 104 F (0 C to 40 C)
° ° ° °
-4 F to 140 F (-20 C to +60 C)
3.5" x 4.7" x 0.9" (90 x 120 x 21.7
mm)
(2 / " deep double gang box recommended)
3
4
NTC (10K)
IMPORTANT NOTICES
FCC Notice
This device complies with Part 15 of the FCC Rules. Operation is subject
to the following two conditions: (1) this device may not cause harmful
interference, and (2) this device must accept any interference received,
including interference that may cause undesired operation.
Warning: Changes or modifications to this unit not expressly approved
by the party responsible for compliance could void the user's authority to
operate the equipment.
NOTE: This equipment has been tested and found to comply with the
limits for a Class B digital device, pursuant to Part 15 of the FCC Rules.
These limits are designed to provide reasonable protection against harmful
interference in a residential installation. This equipment generates, uses,
and can radiate radio frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference will
not occur in a particular installation. If this equipment does cause harmful
interference to radio or television reception, which can be determined by
turning the equipment off and on, the user is encouraged to try to correct
the interference by one or more of the following measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and receiver.
Connect the equipment into an outlet on a circuit different from that to
which the receiver is connected.
Consult the dealer or an experienced radio TV technician for help.
Caution: To maintain compliance with the RF exposure guidelines, place
the unit at least 8" (20 cm) from nearby persons.
IC Statement
This device complies with Industry Canada Licence-exempt RSS-247.
Operation is subject to the following two conditions:
1. This device may not cause interference, and
2. This device must accept any interference, including interference that
may cause undesired operation of the device.
3
