STRATA_HEAT Programmable Thermostat
™
SETTING UP YOUR THERMOSTAT
1. Language – Select your chosen language.
2. System Type – Select your chosen heating system and enter
correct wattage you have connected. Wattage ratings of the heaters can
be found in the heater manual or online at laticrete.com.
3. Set time – Manually set time.
4. Set date – Manually set date.
5. Set daylight savings – Set Europe, N.America, Australia or
switch off.
6. Temperature format – Set the format as degrees Celsius or
Fahrenheit.
7. Home screen style – Set your home screen style.
8. Background image – Set your background style.
9. Display brightness – Set the display and standby brightness.
10. Audio feedback – To turn the touch sounds when making a
selection ON/OFF.
11. Heating target – Control the heating via air or floor sensor.
12. Heating limits – Delicate floor coverings such as vinyl, carpet
and laminate must be limited to 81
°
maximum of 104 F (40
13. Cost setting – Select the rate you are on with your energy
provider and enter cost per kWh.
14. Program setting – Select a preset program, set a fixed
TEST MONTHLY
° °
F (27 C). Tile floors can be set to a
°
C).
09:48 tue 25 apr
78
F
O
air
78 un�l 12:30
82 floor
temperature or set your own custom program.
15. Setback temperature – The setback temperature is the
temperature you set for periods where you would like a lower
temperature or no heating.
SCHEDULING
With your STRATA_HEAT™ Programmable Thermostat, you can choose
to set a custom heating schedule, fixed temperature or a preset program
designed for different rooms.
To adjust a custom program, you must highlight the days that you
want to program by selecting them, then press Program. You can
select multiple days in any combination, for example you can program
separate weekday and weekend temperatures. To do this, program all
the weekdays at once and then program the weekend when you're
finished.
The programming works by setting Comfort Periods of warm
temperatures, shown with a green line. Any time not covered by a
Comfort Period will use a lower Setback temperature to save energy.
The default setback temperature is 61
this once you've set up your program if needed.
You can add up to 4 Comfort Periods per day and when you've set what
you want, just press Done. You'll see the summary of your program
which you can edit by repeating the steps above, or just press Accept to
set your program.
2
Easy Setup Guide
° °
F (16 C) and you can change
