Technical specifications
Cross-line laser ALC 2/1
Visible laser diode
Laser class
Work area
– Horizontal/vertical beam
Precision ...
– Horizontal/vertical beam
Self-levelling range
Power supply
2)
Operating duration
Temperature range
– for operation
– for storage
Weight (with batteries)
1) The measurement range may be less under
unfavourable conditions (bright sunlight,
reflective surfaces).
All manuals and user guides at all-guides.com
635 nm
2
1)
20 m
± 0.3 mm/m
± 4°
3 x LR6/AA
12 h
–5 °C ... 50 °C
–20 °C ... 70 °C
421 g
2) The operating duration was determined with all
activated laser beams. The operating duration can
be extended if beams which are not required are
switched off by selecting a different operating
mode.
Instructions for use
WARNING!
– Do not point the laser beam at people or
animals.
– Do not look into the laser beam.
– Do not put any optical instruments in the path
of the beam.
This measuring instrument generates laser
radiation which may cause blindness.
CAUTION!
– Do not use the measuring instrument in
a damp, dusty or sandy environment.
Device components may be damaged.
– After using the device, immediately switch it
off with the On/Off switch in order to block self-
levelling.
– If the device is brought from a very cold to
a warmer environment or vice versa, you
should allow the device to acclimatise before
using it.
FLEX ALC 2/1–Basic
