Art.-No. Z330-Z336
2. Fit of the
tension bolt
page 2/5
All manuals and user guides at all-guides.com
4. Use a hexagon
screwdriver to screw
into the screw -in dowel
1. Install of the
tensioning element
3. Fasten of the tension
bolt in the tensioning
element with
tensioning screw
Construction Manual
easy-con®
6. Fasten the easy-con®
with a hexagon screwdriver.
5. Insert the tension bolt as far as
possible into the screw-in dowel.
You hear a clear "klick" after snap
into place.
Installation
