Series Connection - 4 Ohm
+
-
-
+
+
-
+ -
-
+
R
L
Speaker Terminal
4. Speaker Connections
NOTE: This amplifier allows 2- or 4-speaker stereo output. Refer to
the connection diagram above for your wiring configuration.
NOTE: The speaker terminal will accept a 12-24 AWG wire. Follow
local codes for routing speaker wires.
Disconnect the power from the amplifier.
Using a wire stripper, remove approximately 1/2" (13 mm) of
insulation from the speaker wire.
Insert the wire into the appropriate positive (+) or negative (-)
and right (R) or left (L) terminal connector.
Repeat for the remaining speaker wires.
Reconnect the power to the amplifier.
Verify that the status LED light turns on.
Kohler Co.
Parallel Connection - 8 Ohm
-
+
+
-
-
+ -
Or
+
+
-
-
+
+
-
-
R
L
11
+
+
-
-
+
-
+
R
L
1232038-2-C
