Get Started
EN
5
Verify the wiring
You may need to modify the wiring of the conventional 3-way switch so that both
switches have a permanent line connection. Before doing this, use the circuit breaker
and a voltage tester to make sure no current is flowing.
Identify the line wire , which is usually attached with a different colored screw or to
1
a terminal marked Common. Disconnect this wire.
Use its color to identify the Traveler wire which is not connected to the blue wire of
2
Eve Dimmer Switch. Disconnect this wire as well.
Use a wire nut and the included extra piece of wire to feed the line connection to
3
both switches: For the conventional 3-way switch, connect the extra piece of wire to
the original terminal (different colored screw/Common) and to the black wire/Line. For
Eve Dimmer Switch, connect the detached traveler wire to the black wire/Line.
Leave the traveler which attaches to the blue input of Eve Dimmer Switch
4
connected to one of the traveler terminals of the conventional 3-way switch.
