ASME A112.18.1 / CSA B125.1
ICC/ANSI A117.1
Model/Modelo/Modèle
21966LF
Series/Series/Seria
Write purchased model number here.
Escriba aquí el número del modelo comprado.
Inscrivez le numéro de modèle ici.
For easy installation of your Delta
faucet you will need:
To READ ALL the instructions completely
before beginning.
To READ ALL warnings, care, and maintenance
information.
To purchase the correct water supply hook-up.
Para instalación fácil de su llave Delta
usted necesitará:
LEER TODAS las instrucciones completamente
antes de empezar.
LEER TODOS los avisos, cuidados, e
información de mantenimiento.
Comprar las conexiones correctas para el
suministro de agua.
Pour installer votre robinet Delta
facilement, vous devez:
LIRE TOUTES les instructions avant de
débuter;
LIRE TOUS les avertissements ainsi que toutes
les instructions de nettoyage et d'entretien;
Acheter le bon nécessaire de raccordement.
66743
You may need/Usted puede necesitar/
Articles dont vous pouvez avoir besoin:
66743
1
6/07/11 Rev. A
Publicité
Manuels Connexes pour Delta 21966LF
Sommaire des Matières pour Delta 21966LF
- Page 1 To READ ALL warnings, care, and maintenance information. To purchase the correct water supply hook-up. Para instalación fácil de su llave Delta usted necesitará: LEER TODAS las instrucciones completamente antes de empezar. LEER TODOS los avisos, cuidados, e información de mantenimiento.
- Page 2 SHUT OFF WATER SUPPLIES. Remove old faucet. Place gaskets (1) Mount spray support (1) in far right hole in sink. on bottom of new faucet. Place faucet through mounting holes in sink. Insert spray hose (1) down through the support and up through center hole of sink.
- Page 3 Secure faucet to sink using locknuts (1) provided. CONNECT TO WATER SUPPLIES. (HOOK-UPS NOT PROVIDED). Determine which type of connection you will be making. (1) Ball nose risers (3/8" O.D. copper tubing) with coupling nuts (not supplied) (A) or (2) 1/2" I.P.S faucet connectors. FLUSH SYSTEM/CHECK FOR LEAKS.
- Page 4 SHUT OFF WATER SUPPLIES A. Remove and clean Aerator (6) RP41673 (page 5), or Replace Stem Unit (1)* and Seats and Springs (2), B. Clean Seats and Springs (2) of any debris. Repair Kit RP71233. *Install stems (1) correctly for proper handle rotation. Note: The stops (3) must point to the center of the faucet for proper handle rotation.
- Page 5 Specify Finish RP42995 Especifíque el Acabado Hot & Cold Lever Handles w/Buttons & Screws Précisez le Fini Manijas en Palanca con Botones y Tornillos de agua fría y caliente Manettes-leviers d’eau chaude et d’eau froide avec boutons et vis RP41673 Aerator Aireador Aérateur...
- Page 6 MAKE ANY OTHER WARRANTY OF ANY KIND, INCLUDING THE IMPLIED WARRANTY OF MERCHANTABILITY. Delta will replace, FREE OF CHARGE, during the warranty period, any part or finish that proves defective in material and/or workmanship under normal installation, use & service. Replacement This warranty excludes all industrial, commercial &...
