ASME A112.18.1 / CSA B125.1
ICC/ANSI A117.1
Model/Modelo/Modèle
21996LF
Series/Series/Seria
Write purchased model number here.
Escriba aquí el número del modelo comprado.
Inscrivez le numéro de modèle ici.
For easy installation of your Delta
faucet you will need:
To READ ALL the instructions completely
before beginning.
To READ ALL warnings, care, and maintenance
information.
To purchase the correct water supply hook-up.
Para instalación fácil de su llave Delta
usted necesitará:
LEER TODAS las instrucciones completamente
antes de empezar.
LEER TODOS los avisos, cuidados, e
información de mantenimiento.
Comprar las conexiones correctas para el
suministro de agua.
Pour installer votre robinet Delta
facilement, vous devez:
LIRE TOUTES les instructions avant de
débuter;
LIRE TOUS les avertissements ainsi que toutes
les instructions de nettoyage et d'entretien;
Acheter le bon nécessaire de raccordement.
All manuals and user guides at all-guides.com
You may need/Usted puede necesitar/
Articles dont vous pouvez avoir besoin:
1
4/9/10 Rev. B

Publicité

loading

Manuels Connexes pour Delta 21996LF

Sommaire des Matières pour Delta 21996LF

  • Page 1 To READ ALL warnings, care, and maintenance information. To purchase the correct water supply hook-up. Para instalación fácil de su llave Delta usted necesitará: LEER TODAS las instrucciones completamente antes de empezar. LEER TODOS los avisos, cuidados, e información de mantenimiento.
  • Page 2 All manuals and user guides at all-guides.com SHUT OFF WATER SUPPLIES. Remove old faucet. Place gasket (1) Mount spray support (1) in far right hole in sink. on bottom of new faucet. Place faucet through mounting holes in sink. Align tabs (1) and tabs (2) on quick connects (3). Push quick Option: If sink is uneven, use silicone under the gasket.
  • Page 3 All manuals and user guides at all-guides.com Secure faucet to sink using locknuts (1) provided. CONNECT TO WATER SUPPLIES. (HOOK-UPS NOT PROVIDED). Determine which type of connection you will be making. (1) Ball nose risers (3/8" O.D. copper tubing) with coupling nuts (supplied) (A) or (2) 1/2"...
  • Page 4 All manuals and user guides at all-guides.com A. Remove and clean Diverter Assembly (5), or SHUT OFF WATER SUPPLIES B. Replace Diverter Assembly (5), Repair Kit RP41702. Replace Stem Unit (1)* and Seats and Springs (2), A. Remove and clean Aerator (6), or Repair Kit RP54801 or RP41701.
  • Page 5 All manuals and user guides at all-guides.com Specify Finish Especifíque el Acabado Précisez le Fini RP41679 Hot & Cold Lever Handles w/Buttons & Screws Manijas en Palanca con Botones y Tornillos de agua fría y caliente Manettes-leviers d’eau chaude et d’eau froide avec boutons et vis Order this RP number if your Order this RP number if your...
  • Page 6 MAKE ANY OTHER WARRANTY OF ANY KIND, INCLUDING THE IMPLIED WARRANTY OF MERCHANTABILITY. Delta will replace, FREE OF CHARGE, during the warranty period, any part or finish that proves defective in material and/or workmanship under normal installation, use & service. Replacement This warranty excludes all industrial, commercial &...
