Quick Start
Quick Start
The following chart summarises the connection process for the
MultiSync XV17+.
For more details please turn to the following pages if you are connecting
to an IBM compatible, Macintosh compatible or other systems.
Is the computer a Macintosh
Computer?
No
Attach the signal cable of the moni-
tor to the video board/Mac adapter.
Connect the power cord of the
monitor to the power outlet and to
the monitor itself.
Turn monitor and computer on.
If necessary, use the OSM controls
for personal preference of the image.
Is the image correct?
Yes
Enjoy your monitor.
Use the optional MultiSync
Yes
Mac adapter to attach the
monitors signal cable to the
Macintosh video output.
See the Trouble Shooting section
No
Yes
Call your NEC-Dealer
Problem solved?
No
E - 7
