• Installed program on remote PC to send commands:
In general, the RS-232 commands are sent for operating the implemented functions via serial port and utility.
A suitable utility can be used such as described below.
Connecting to the TV (LAN port)
Download and install the PuTTY software from the following link first: http://www.putty.org/.
Run the software and enter the TV's IP address in the
field Host Name. Enter "1986" as a default value in the
field Port. Then select "Telnet" as Connection type and
click the Open button.
Note: Refer to the Connectivity section of this manual for
information on connecting the TV to a network and displaying
the IP address of the TV.
Use the commands in the RS232/LAN Command
Table.For example, if "GETVOLUME" command is
entered, current volume level should be displayed on
the putty window as shown in the pictures below.
Another example;
Volume level can be changed by using "VOLUME"
command. After sending this command, you can verify
the changes from the TV.
The last example ;
When "GETSOURCE" command is entered, current
source should be displayed on the putty window as
shown in the picture below.
English - 11 -
