Digital ADAS 2.0
Installation manual
Bar assembly on the structure
7 Insert the sliding trolleys into the bar,
following the order shown in the figure
8 Close the end by refitting the plate
and tightening the fixing screws
(M3x6)
9 Place the 3 fasteners with screws on
the structure
Proceed with the centering of the bar,
10
positioning it so that its center is in the
middle of the two central posts (22
cm on both sides)
Note: Use a measuring tape or laser
rangefinder for accurate measurement
11 Place the screws in the appropriate
holes on the pre-assembled structure
12 Tighten the screws with the self-lock-
ing nuts and flat washers, using the
10 mm socket wrench
