8870685
PARTS LIST
#
DESCRIPTION
1
Air Nozzle
2
Ring
3
Brass Cap
4
Fluid Nozzle
5
Packing Screw For Paint
Needle
6
Teflon Seal
7
Washer
8
Spring
9
Brass Ring
10
Gasket
11
Connector For 0.6 litre Cup
12
Gun Body
13
Screw
13C Teflon Seal
13D Body
13E P. C. Seal
13F Valve
13G Valve
13H Spring
14
Washer
14A Spray Regulating Screw
14B Spray Regulating Nut
14C Teflon Seal
15
Pattern Adjustment Valve
Knob
15A Countersunk Screw
16
Paint Needle-Complete
18
HVLP Gravity Paint Gun
17
18
18A Fluid Control Knob
23
24
24A Clip
25
26
27
28
28A Adaptor
29
29B Non-Drip Control Device
32
33A Air Inlet Valve
33B Air Valve Spring
33F O-ring
33G Air Adjustment Knob
33H Air Adjustment Screw
For technical questions call 1-800-665-8685
Spring For Paint Needle
Lockout For Fluid Control
Knob
Trigger
Screw
Pin
Air Connection Piece 1/4 In.
BSP
Material Sleeve
Nylon Cup
Cover Of 0.6 Litre Nylon Cup
Brush
V4.0
