4.6 Handover
➜ Proceed in accordance with the "Handover check list" in
section 9.3.
5
dIsassEmbly and dIsposal
packaging
➜ Dispose of the packaging in accordance with the local
regulations.
panElle Enlight
1. Have PanElle Enlight disconnected from the power
supply by an electrician.
2. Disassemble PanElle Enlight.
3. Return PanElle Enlight to Duscholux.
6
HElp WItH malFunctIons
We are readily available to answer any queries
you may have. You can find our contact details
on the last page of these assembly instructions.
7
tEcHnIcal data
Electrical data
Input voltage
Output voltage
Protection type
Protection class
lEd light strip
Version
Operating voltage
Power consumption
Colour temperature
Protection type
Protection class
Long connection cable
4
All manuals and user guides at all-guides.com
230 V AC
24 V DC
IP 20
II
PanElle with integrated LEDs
24 V DC
10 W/m
6500 k
IP 65
III
5 m
8
sErVIcE and sparE parts
• A guarantee number can be found at the end
of these assembly instructions. Your can use
this for guarantee claims.
• We are readily available to answer any que-
ries you may have. You can find our contact
details on the last page of these assembly
instructions.
9
cHEck lIsts
9.1 check list of connection requirements
Electrical installation
Protection zones maintained
Cable connection inspected
Power adapter output observed
plumbing installation
panElle Enlight: Connection profile assembled and
silicone-sealed in accordance with the instructions
(figure 13 and 17)
Shower or shower area tiled
9.2 assembly/installation check list
Application surface suitable for fastening material?
Mounting position vertical/horizontal and even
9.3 Handover check list
Cleaned
Operation checked
Note: Regularly check the silicone joints
Handover of the assembly instructions to the user
(guarantee number).
Location, Date, Time
Name
EN
❑
❑
❑
❑
❑
❑
❑
❑
❑
❑
❑
❑
Company
Signature
