ENGLISH
DEVICE LAYOUT
1. USB out
2. Type-C out
3. US AC plug
4. AU AC plug
5. EU AC plug
6. UK AC plug
SPECIFICATION
Input connector
Input voltage
Output voltage
Load regulation
Output current
Output ripple
Efficiency
Short protection
Total output
USB-A 1 output
USB-A 2 output
Type-C 1 output
Type-C 2 output
TO CHARGE YOUR DEVICES
1. Choose the required AC plug and insert into the hub.
(To remove the AC plug press the "PUSH" button on the AC plug and
remove the AC plug.)
2. Insert the charger into the wall socket.
3. Connect your device to the charger using your USB cable (not supplied).
4. After charging your device. disconnect the items in reversed order.
The output of this item is parallel. This means the output is 15W for all ports.
It does not matter if two or more items charge at the same time.
1.
2.
4.
US/AU/EU/UK AC plug
AC100-240V 50/60Hz 0.6A
5.0V
4.75V-5.25V
3A
200mV (Max.)
≥81.39%
Auto recovery
15W
5V/3A
5V/3A
5V/3A
5V/3A
3.
5. 6.
