2. Conformity with standards
The T-M-20-S/+x+y/EX meets the requirements of EN 50 014:1997,
EN 50 018:1994 and EN 50 019:1994. It is developed, manufactured and
tested in accordance with state-of-the-art engineering practice end
EN 29 001.
After being tested successfully for proper functioning, the temperature
controller and limiter also complies with standards EN 60 730 Part 1 and
Parts 2-9.
3. Technical data
Explosion protection
EC Type Examination Certificate
Enclosure material
Rated voltage
Switching capacity
Hysteresis/ Differential
Terminal size
Environmental protection
Admissible ambient temperature
Designation
EEx ed IIC T6 T80°C
PTB 01 ATEX 1075
Glass filled polyester
Max 250 to 400VAC
Max 16A at 400VAC
Controller <= 6 K
Limiter <=4 K
11 x 4 mm
IP 65
–20°C to +80°C
220
204
2
0102
II 2 G/D
82
120
90
5
